Rated speed：≤2.5 m/s

Rope pulley pitch diameter：φ240mm
Wire rope diameter：standard configuration φ8mm , optional φ6mm(Partial speed)

Lifting force：≥1000N

Tension device：standard configuration HHZJ01，optional HHZJ02、HHZJ03

Supply voltage：/
Working Position：Car side or counterweight side

Uplink control：Counterweight safety gear

Downward control：safety gear

Reset mode：Electrical switch manual reset, mechanical mechanism manual reset
