Rated speed：≤1.0m/s

Rope pulley pitch diameter：φ180mm
Wire rope diameter：standard configuration φ6mm

Lifting force：≥650N
Tension device：standard configuration TZJ180
Supply voltage：standard configuration AC220V，optional DC24V

Working Position：Car side or counterweight side

Uplink control：Synchronous traction machine brake and counterweight safety gear

Downward control：safety gear

Remote control：Electrically controlled testing actions and their electrical switches can be reset, and mechanical mechanisms can automatically reset
