Rated speed：≤0.63m/s；1.0m/s；1.5~1.6m/s；1.75 m/s

Rope pulley pitch diameter：φ240mm

Wire rope diameter：standard configuration φ8mm ,optional φ6mm(Partial speed)

Lifting force：≥500N

Tension device：standard configuration OX-300，optional OX-200

Supply voltage：standard configuration AC220V，optional DC24V

Working position：Car side or counterweight side

Uplink control：Synchronous traction machine brake and counterweight safety gear

Downward control：safety gear

Remote control：lectrically controlled testing actions and their electrical switches can be reset, and mechanical mechanisms can automatically reset
